Perfect Solution Contracting provides complete electrical raceway and cable support solutions for power, lighting, control, and other electrical systems in commercial buildings, industrial facilities, infrastructure projects, utilities, data centers, and other facilities.

Electrical raceways provide defined routes for electrical conductors and cables while supporting mechanical protection, organization, accessibility, segregation, and coordination with the building and other services.

Cable support systems such as cable trays and cable ladders provide structured support and routing for groups of cables and are selected according to cable type, quantity, weight, installation environment, routing requirements, and approved project design.

Our scope can include engineering coordination, technical and material submittals, supply, installation, fittings, boxes, supports, anchors, hangers, clamps, sleeves, bonding, fire stopping, inspection, testing, and final handover according to project requirements.

Electrical Raceway Systems

Raceway systems are selected according to the type of electrical installation, conductor requirements, mechanical protection, environmental conditions, installation method, accessibility, and approved electrical specifications.

Depending on the project, raceways can be installed concealed within walls, slabs, and ceilings or exposed within electrical rooms, plant areas, service spaces, and other approved locations.

Raceway routing is coordinated with architectural, structural, mechanical, plumbing, fire-protection, low-current, and other building services to minimize conflicts and maintain required access.

EMT Conduits

Electrical Metallic Tubing (EMT) can be used for applicable electrical installations where permitted by the project specification and installation environment.

EMT installations include approved couplings, connectors, boxes, bends, supports, fittings, and accessories suitable for the selected conduit system.

IMC & RMC Conduits

Intermediate Metal Conduit (IMC) and Rigid Metal Conduit (RMC) can be used where increased mechanical protection or specific installation characteristics are required.

The conduit type, coating, fittings, and installation arrangement are selected according to the environment, mechanical exposure, corrosion conditions, and project requirements.

PVC & UPVC Conduits

Non-metallic conduit systems such as PVC / UPVC can be used for applicable concealed, embedded, underground, or other approved installations depending on the conduit classification and project requirements.

Selection considers conduit strength, installation environment, temperature, mechanical protection, underground conditions where applicable, fittings, bends, and compatibility with the intended cable installation.

Flexible Conduits

Flexible conduit can be used for final connections to equipment where movement, vibration, alignment, or maintenance requirements make a rigid connection unsuitable.

Applications can include motors, pumps, fans, mechanical equipment, and other electrical equipment where flexible connections are required by the approved installation.

The selected flexible conduit and fittings should be suitable for the installation environment, including moisture or other exposure conditions where applicable.

Cable Trays

Cable tray systems provide organized support and routing for power, control, instrumentation, and other cables where permitted by the approved electrical design.

Cable tray selection considers cable quantity, cable diameter, total cable weight, allowable tray loading, support spacing, required spare capacity, environmental conditions, and routing.

Tray systems can include straight sections, horizontal and vertical bends, tees, crosses, reducers, connectors, covers where required, supports, and other accessories needed for the approved route.

Cable Ladder Systems

Cable ladder systems can be used for supporting power and other suitable cables, particularly where cable loading, ventilation, accessibility, and routing requirements make ladder construction appropriate.

Ladder width, side-rail height, rung spacing, material, support spacing, fittings, and load capacity are selected according to the cables and project requirements.

Electrical Trunking

Electrical trunking systems can provide enclosed routing and distribution paths for conductors and cables in electrical rooms, service areas, commercial spaces, and other approved applications.

Trunking size, material, covers, fittings, compartments, supports, and accessories are selected according to the number and type of conductors and the required installation arrangement.

Raceway & Cable Tray Materials

Raceway and cable-support materials are selected according to the installation environment and approved project specification.

Depending on the system, materials and finishes can include galvanized steel, hot-dip galvanized steel, stainless steel, aluminum, PVC/UPVC, or other approved materials suitable for the intended application.

Corrosion resistance is particularly important for outdoor installations, humid areas, industrial environments, and locations exposed to aggressive environmental conditions.

Raceway Sizing & Conduit Fill

Conduit and raceway sizing is coordinated with the number, type, and size of conductors to provide the required installation space and facilitate cable pulling.

Applicable conduit-fill requirements, conductor dimensions, bends, route length, and pulling conditions are considered when selecting the raceway size.

Oversized or undersized raceways should not be selected arbitrarily. Raceway dimensions are determined according to the actual cable arrangement and applicable project requirements.

Cable Tray Capacity

Cable tray and ladder dimensions are coordinated with the quantity and arrangement of installed cables, allowable loading, cable spacing where required, and specified spare capacity.

Future capacity should be included only where required by the project design rather than assuming a universal spare percentage for every installation.

Cable Weight & Structural Loading

Cable support systems are selected to support the installed cable weight together with the applicable system loading and support conditions.

Tray and ladder loading should be coordinated with support spacing, fitting locations, changes in direction, concentrated loads where applicable, and the load ratings of the selected system.

Supports, Hangers & Anchors

Raceway and cable-support installations include suitable supports, hangers, brackets, channels, threaded rods, clamps, anchors, and other structural support accessories according to the approved installation arrangement.

Support spacing depends on the raceway or tray type, dimensions, loading, manufacturer requirements, installation orientation, fittings, and project specifications.

Supports should be coordinated with the building structure, and attachment to other building services should not be assumed unless specifically engineered and approved.

Boxes & Fittings

Raceway systems can include pull boxes, junction boxes, outlet boxes, inspection boxes, couplings, connectors, adapters, bushings, locknuts, bends, and other accessories required for a complete installation.

Box sizing and positioning are coordinated with conductor quantities, cable-pulling requirements, accessibility, route changes, and maintenance needs.

Cable Pulling & Bending Requirements

Raceway routing should allow cables and conductors to be installed without exceeding the applicable bending limitations or creating unacceptable pulling conditions.

Pull points, boxes, bends, and route geometry are coordinated with the cable type, conductor size, pulling length, and installation method.

For larger power cables, cable manufacturer's pulling tension and minimum bending-radius requirements should be considered during route planning and installation.

Cable Segregation

Raceway and cable-support layouts are coordinated to maintain the required segregation between different electrical systems according to the approved project design.

Power, emergency, control, instrumentation, fire-alarm, communication, and other systems can require separate routes, barriers, spacing, or other segregation measures depending on the project requirements.

Segregation requirements should be determined by the system design and applicable specifications rather than applying one universal separation distance to all installations.

Earthing & Bonding

Metallic raceways, cable trays, cable ladders, trunking, boxes, and associated metallic components are coordinated with the electrical earthing and bonding system.

Electrical continuity across joints and fittings is maintained according to the selected system and approved installation requirements.

Where dedicated bonding conductors or bonding jumpers are required, their size and installation are determined according to the electrical design and applicable project requirements.

Sleeves & Building Penetrations

Electrical routes passing through walls, floors, slabs, and other building elements are coordinated with suitable sleeves and approved penetration details.

Sleeve size, material, location, and installation are coordinated with the raceway or cable system, structural requirements, waterproofing where applicable, and the required penetration treatment.

Fire Stopping

Where raceways or cables penetrate fire-rated walls, floors, or other fire-rated assemblies, the penetrations are treated using approved fire-stopping systems appropriate for the penetration configuration.

Fire-stopping requirements are coordinated with the type of wall or floor assembly, penetration size, cables or conduits passing through it, and the approved project fire-safety requirements.

Outdoor & Wet-Area Installations

Raceways and cable-support systems installed outdoors or in wet, humid, or exposed environments require materials, fittings, supports, and finishes suitable for the applicable environmental conditions.

Weather exposure, moisture, corrosion, UV exposure, drainage, ingress protection of associated boxes, and equipment interfaces are considered according to the installation location.

Underground Raceway Systems

Underground electrical routes can include approved ducts or conduits, duct banks, sleeves, pull chambers, manholes, warning arrangements, and other components required by the project design.

Underground installations are coordinated with burial depth, mechanical protection, road crossings, structural loading, drainage, other utilities, cable pulling requirements, and approved civil details.

Expansion & Movement

Where electrical raceways or cable-support systems cross structural expansion joints or locations subject to movement, suitable arrangements are provided to accommodate the expected movement where required.

Expansion fittings, flexible connections, sliding supports, or other approved arrangements are selected according to the raceway type and structural movement requirements.

Connections to Vibrating Equipment

Flexible connections can be provided between rigid raceways and equipment subject to vibration or movement, such as motors, pumps, fans, and other mechanical equipment.

The flexible connection is selected according to the environment, movement, electrical requirements, and equipment connection arrangement.

MEP & BIM Coordination

Raceway and cable tray routing requires coordination with other MEP systems to maintain installation clearances, access to equipment, ceiling-space requirements, and constructability.

Where required by the project, BIM coordination can be used to review electrical routes against structural, mechanical, plumbing, fire-protection, architectural, and other services before installation.

Shop Drawings & Technical Submittals

Technical submittals can include product data, materials, dimensions, load ratings, finishes, fittings, supports, environmental suitability, and other information relevant to the selected raceway or cable-support system.

Shop drawings can identify conduit routes, cable tray and ladder routes, sizes, elevations, fittings, support arrangements, sleeves, penetrations, and interfaces with electrical equipment.

Installation Inspection

Installed raceways and cable-support systems are inspected for routing, alignment, supports, fittings, joints, mechanical condition, accessibility, segregation, bonding, penetrations, and compliance with the approved drawings.

Cable trays and ladders are also checked for correct support spacing, secure connections, required fittings, route continuity, cable loading, and installation condition.

Raceway Verification

Before cable installation, raceways can be checked to verify that routes are complete, accessible, free from obstructions, and suitable for the intended conductors or cables.

Pull wires or draw ropes can be installed where required to facilitate subsequent cable installation.

Testing & Handover

Inspection and testing requirements depend on the installed raceway and support system and can include verification of mechanical installation, electrical continuity and bonding where applicable, support integrity, and completion of required penetration treatments.

Final handover documentation can include approved material submittals, inspection records, test records where applicable, approved shop drawings, and as-built documentation according to project requirements.

Standards & Project Requirements

Electrical raceways and cable-support systems are selected and installed according to the approved project specifications, manufacturer requirements, installation conditions, and relevant standards applicable to the selected system.

The applicable requirements depend on the raceway, conduit, trunking, cable tray, or cable ladder system being used. Standards and product requirements should therefore be applied according to the specific system rather than assuming that one standard covers every type of raceway and cable support.

Perfect Solution Contracting provides complete electrical raceway and cable-support solutions covering engineering coordination, technical submittals, procurement, installation, supports, fittings, sleeves, bonding, fire stopping, inspection, testing, and final handover according to the approved project scope.
